Haesung Electronics,
a company specializing in materials/parts/equipment

Haesung Electronics is currently registered as a ‘company specializing in materials/parts/equipment’, and, in particular, is designated as a government-sponsored smart factory business factory coping with the flow of the 4th industrial revolution.

Haesung Electronics takes pride in that it constructed the best system and produces the best products in the industry, and promises to use the best endeavors to achieve customer satisfaction based on such pride.

01 Production Process

  • 01
    Wire Cutting Process
    A monthly capacity of 1,2000,000 pieces(based on 300mm)
  • 02
    Manual Crimping Process
    A monthly capacity of 2,000,000 pieces
  • 03
    UV Coating Process
    A monthly capacity of 200,000 pieces
  • 04
    Auto Crimping Process
    A monthly capacity of 1,800,000 pieces
  • 05
    Injection Molding Process
    A monthly capacity of 300,000 pieces
  • 06
    Electric Harness Plate Process
    A monthly capacity of 20,000 pieces(based on quarter point 20)
  • 07
    Assembly Process
    A monthly capacity of 300,000 pieces (based on 10PIN)

02 Inspection Process

  • 01
    Inspection Using Microscope
    3 Electronic Microscopes
  • 02
    Vision Inspection
    Vision Inspection system 2대
  • 03
    Circuit Inspection
    6 Circuit Inspectors
  • 04
    Inspection Using Magnifier
    8 Magnifiers
  • 05
    Resistance Test
    3 Resistance Testers
  • 06
    Terminal Cross-section Inspection
    2 Terminal Cross-section Inspectors
  • 07
    Tensile Force Test
    3 Tensile Force Testers
